EasyCast J – Jewelry Casting System

///EasyCast J – Jewelry Casting System
EasyCast J – Jewelry Casting System2018-09-13T05:05:16+00:00

EasyCast J is a compact and affordable centrifugal casting system perfect for small jewelry manufacturers or boutique shops.

This universal casting machine can cast all metals and alloys: precious and non-precious. Centrifugal injection with high-acceleration casting provides high quality, consistent results.

Advanced, efficient technology with automatic frequency setting and low
energy consumption.

EasyCast utilizes fast melting using state-of-the art induction heating
generator utilizing the latest technology.

Reward: Casting in vaccuum and inert gas atmosphere guaranties complete protection from oxidation.

Integrated Infrared temperature control guarantees casting quality and repeatability.

The reliable modular system, is to maintain and service.

FEATURES

  • Centrifugal injection jewelry casting system with pneumatic movement for fast coil descent
  • Internal water cooling system with pressure and water temperature control
  • Centrifugal arm balancing with adjustable counterweight
  • Advanced digital control panel with status and diagnostics messages
  • Melting power regulation from 10% to 100%
  • DC motor with reduction gear and adjustable acceleration from 0.1 to 1 sec.
  • Max rotating speed – 500 rpm. Rotation timeout pre-set at 40 sec.
  • Auto locking of the chamber lid during centrifugal phase for maximum safety
  • Integral vacuum pump (EC-12 model)
  • Inert (argon or nitrogen) gas circuit included (EC-12 model)

APPLICATIONS

EC-11
0UPT-015-500
EC-12
0UPT-017-510
Power (max)3.0 kW3.0 kW
AC Line, (50/60Hz), 1 Phase230 ±10%230 ±10%
Melting Temperature (max)2000 °C2000 °C
Crucible Capacity150g Pt (30g min)150g Au, 80g Ag150g Pt (30g min)150g Au, 80g Ag
Crucible VolumeGraphite insert 10 cm3
Ceramic 30 cm3
Graphite insert 10 cm3
Ceramic 30 cm3
Flask Size (max), DxH80 mm x 75 mm80 mm x 75 mm
IR Temperature reader/regulatorn/aincluded
Water Cooling Systemincludedincluded
Vacuum Pumpn/aincluded
Weight100 kg (220.5 Lb)110 kg (242.5 Lb)
Dimensions, LxWxH53 cm x 65.7 cm x 105 cm
(20.9” x 25.9” x 41.3”)
53 cm x 65.7 cm x 105 cm
(20.9” x 25.9” x 41.3”)
  • Improved energy efficiency
  • Higher degree of controllability
  • Increased repeatability
  • Low maintenance requirements
  • Increased productivity
EquipmentDescriptionPart NumberPictures
HE-017Heat exchanger1ACC-017-510-00
Part NumberDescriptionEasyCast-11EasyCast-12
Induction System2DET-015-000-KAGraphite crucible
Material: ceramic with graphite.
Suitable for: Gold, Silver, Brass, Copper, Aluminum, Bronze
Max Capacity: 170 g Gold.
Average life: about 30 castings
Volume: 10 cm3
Max Temperature of the metal: 1300C
11
Induction System2DET-015-000-KFCeramic crucible
Suitable for: platinum and steel
Max Capacity: 200 g Pt.
Min Capacity: 40g Pt
Average life: about 30 castings
Volume: 30 cm3
Max Temperature of the metal: 1800C
11
Tongs for induction casting4HVM-000-101-00Crucible tongs11
induction heater2DET-017-450-OFPad (spacer) for Pt crucible11
Screwdriver system “ZERO” for induction casting and melting machine4HVM-000-100-00Screwdriver system “ZERO”11
induction heater4EAC-000-028-00T-allen key 5mm11
induction casting4EAC-000-017-00Anti vibration feet11
